REGO ECL502-22 1/4″ Brass Cryogenic Economizer 10-60 PSIG 22 PSI O2 Clean

SKU: ECL502-140

Weight	2 lbs
Dimensions	8 × 8 × 8 in

$329.00

In stock — available to order.

Sold individually. Each quantity ordered is one unit. Kits are one complete kit; products sold by length use the stated length unit.

Same-item volume pricing

Quantity	Unit price	Saving
1–4	$329.00	0%
5–9	$312.55	5%
10+	$296.10	10%

Estimate for this quantity before shipping. Tax display follows store settings. Existing cart quantities can increase the tier. Only one offer applies; a coupon replaces automatic pricing. For 20+ units, contact support for a quote.

Available to order.

Bulk quantity & quote

Quantity needed

Enter the total quantity you need. We will confirm availability and a quote before you order.

Need a firm ship date? Availability may include supplier stock. Confirm availability before ordering for time-sensitive work.

REGO ECL502-22 1/4" Brass Cryogenic Economizer 10-60 PSIG 22 PSI O2 Clean

Specifications & product details

Description

REGO ECL502-140 Brass Cryogenic Economizer – 1/4″ FNPT – 140 PSIG

Industrial-quality REGO ECL502-140 cryogenic economizer designed to help maintain desired system pressure in cryogenic cylinder and LNG applications.

The valve is normally closed below its pressure set point and opens as pressure rises above the set point, helping utilize excess vapor pressure and maintain system pressure. It features brass construction with cryogenic-compatible PTFE, stainless-steel, bronze and Monel internal components.

Key Features

Factory set at 140 PSIG
50–175 PSIG operating range
1/4″ female NPT inlet and outlet
Brass body and bonnet
Suitable for cryogenic service
Cleaned for oxygen service per CGA G-4.1
Bi-directional flow capability for LNG systems
150-mesh Monel inlet/outlet screens
Operating temperature down to -320°F
Maximum allowable working pressure: 375 PSIG
Suitable for nitrogen, oxygen, argon and other compatible cryogenic applications

Specification	Details
Brand	REGO
MPN / Part Number	ECL502-140
Product Type	Cryogenic Economizer / Back Pressure Regulator
Body Material	Brass
Port Size	1/4″
Connection	1/4″ FNPT Inlet × 1/4″ FNPT Outlet
Factory Pressure Setting	140 PSIG
Operating / Delivery Range	50–175 PSIG
Maximum Allowable Working Pressure	375 PSIG
Temperature Range	-320°F to +165°F (-196°C to +74°C)
Oxygen Service	Cleaned for oxygen service per CGA G-4.1
Flow	Bi-directional
Body / Bonnet	Brass
Diaphragm	Bronze with PTFE liner
Screen	Monel, 150 mesh
Springs / Adjusting Screw	Stainless steel
Poppet Seat	Stainless steel
Adjustment	Screw with locknut
Overall Height	Approx. 3.5 in.
Width	Approx. 2.25 in.
Applications	Oxygen, Nitrogen, Argon, LNG and other compatible cryogenic systems
